5g/In Anti Static PET Film Custom Width Anti Static PET Film Roll

5g/In Anti Static PET Film Custom Width Anti Static PET Film Roll

Brand Name: HUAMEI
Model Number: Silicone Release Film
MOQ: 6200 square meter
Price: 0.24-1.64/㎡
Payment Terms: L/C,D/P
Supply Ability: 300000m everyday
Detail Information
Place of Origin:
CHINA
Raw Material:
PET
Color:
Customized
Width:
Customized According To User Needs
Length:
Customized According To User Needs
Thickness:
19-150
Release Force:
5 Or Customized
Residual Adhesion Rate:
≥80
Packaging Details:
Wrapping Film Protection+Carton Package+Tray Package
Supply Ability:
300000m everyday
Highlight:

5g/In Anti Static PET Film

,

polyester release film 5g/In

,

Anti Static PET Film Roll

Product Description

5g / in Antistatic PET Release Film Custom Width Anti-static PET Film Roll



››› Product Introduction

PET substrate using a high-performance, front coated with release coating, antistatic treatment on the back, making products with anti-static function, reduce negative phenomena caused by static electricity.





››› Product Features

1.Producing in the 1000-level clean environment, with high cleanness;

2.It has stable antistatic effect and good weather resistance;

3.Residual adhesion rate 85%, no performance impact on the bonding material, non-polluting;

4.Optical Clarity:High transparency allows visual inspection of protected materials without removing the film.

5.Thermal and Chemical Resistance:Withstands temperatures up to 120°C, suitable for high-temperature processing.





››› Product Structure



5g/In Anti Static PET Film Custom Width Anti Static PET Film Roll 0







››› Product Use

1. Printing Industry

Digital Printing: Anti-static PET film is used as a substrate in digital printing applications to prevent static buildup that can attract dust and cause printing defects.

Screen Printing: It is used in screen printing processes to ensure that the film does not attract dust or other particles that could affect print quality.

2.Medical Industry

Protective Films: Anti-static PET film is used in the production of protective films for medical devices and equipment where static discharge could interfere with sensitive electronic components.

Packaging for Medical Devices: It is used in the packaging of medical devices to prevent static buildup that could attract contaminants.

3.Manufacturing and Processing

Conveyor Belts: Anti-static PET film is used in the production of conveyor belts for industries where static discharge can cause issues, such as in the handling of plastics and other materials.

Laminating: The film is used in laminating processes where static control is necessary to ensure a smooth and bubble-free finish.





››› Product Packaging

1.Products are generally used by cardboard tray, nude tray packaging;

2.All cartons of products have certificate, packing list, each tray should have a list of products;

3.Our products can also be packaged according to the requirements of the user agreement.





››› Product Performance



Project Eigenvalues
Membrance Raw materials PET
Color Customized according to user needs
Width(mm) Customized according to user needs
Length(mm) Customized according to user needs
Thickness(μm) 19-150
Surface resistivity(Ω·m) 10^5-10^9,10^9-10^11
Coating color Light grey,transparent,light blue
Solvent resistant wiping Customized according to user needs
Release Force(g/in) 5
Residual adhesion rate(%) ≥80

Conventional range

from the type of power

2±1,4±1,7±2,10±3,15±5,20±5,25±5,30±5,35±5,45±10,50±10,60±10,70±15,90±15,100±20,120±20,150±30









FAQ

 Q   Are you a manufacturer or trading company?

 A   We are a professional manufacturer with over 15 years experience.



 Q   What about the lead time for mass production?

 A   7-14 days.



 Q   How can I get the free sample?

 A   We provide the free sample.Please tell us which model you want and pay the freight,then we will ship out the samples.



 Q   What about the payment?

 A    L/C,D/P.



 Q   How can we grantee quality?

 A    We adopt advanced chemical and coating technology from Japan, and are equipped with equipment such  as slitting machines,tensile testing technology, ROHS detectors,and constant temperature and humidity  environmental testers.
